Simpson Strong-Tie HD5SS

The Simpson Strong-Tie® HD holdown is designed to create high allowable loads for both vertical and horizontal applications in wood construction. This holdown is installed with bolts into posts or columns. The HD can be installed back to back when eccentricity is an issue.

Ask a Question
Specifications

Simpson Strong-Tie HD5SS

•High-capacity low-deflection holdown
•Self-jigging, ensuring the code-required minimum of seven bolt diameters from the end of the post when installed flush with the sill plate
•May be raised and installed off the sill plate
•Width: 2-7/8 in.
•Height: 6-3/8 in.
•Base: 3 in. steel
•Body: 7-gauge steel
•Stainless steel offers extra corrosion resistance for exterior and treated-wood applications


Description

Simpson Strong-Tie HD5SS

The Simpson Strong-Tie® HD holdown is designed to create high allowable loads for both vertical and horizontal applications in wood construction. This holdown is installed with bolts into posts or columns. The HD can be installed back to back when eccentricity is an issue.
