Simpson Strong-Tie HD7SS HD 11-3/4 in. Stainless-Steel Bolted Holdown

$204.66

MPN: HD7SS

Brand: Simpson Strong-Tie
Barcode: 707392772569
Availability : Limited Stock Out of stock

Type: Holdown

Holdown
Add to Wishlist

Minimum order quantity is .

Maximum order quantity is .
The product can be bought in quantity increments of .

Simpson Strong-Tie HD7SS

The Simpson Strong-Tie® HD holdown is designed to create high allowable loads for both vertical and horizontal applications in wood construction. This holdown is installed with bolts into posts or columns. The HD can be installed back to back when eccentricity is an issue.

Ask a Question
Specifications

Simpson Strong-Tie HD7SS

•High-capacity low-deflection holdown
•Self-jigging, ensuring the code-required minimum of seven bolt diameters from the end of the post when installed flush with the sill plate
•May be raised and installed off the sill plate
•Width: 3-1/2 in.
•Height: 11-3/4 in.
•Base: 5/16 in. steel
•Body: 3-gauge steel
•Stainless steel offers extra corrosion resistance for exterior and treated-wood applications


Description

Simpson Strong-Tie HD7SS

The Simpson Strong-Tie® HD holdown is designed to create high allowable loads for both vertical and horizontal applications in wood construction. This holdown is installed with bolts into posts or columns. The HD can be installed back to back when eccentricity is an issue.

Additional Information
Type

Holdown
