Simpson Strong-Tie NRU46Z NRUZ ZMAX® Galvanized Retrofit Hanger for 4x6

$55.26

MPN: NRU46Z

Brand: Simpson Strong-Tie
Barcode: 707392555902
Availability : Limited Stock Out of stock

Type: Hanger

Hanger
Add to Wishlist

Minimum order quantity is .

Maximum order quantity is .
The product can be bought in quantity increments of .

Simpson Strong-Tie NRU46Z

The NRUZ series of retrofit hangers is designed for use on nailers on steel trusses. It is designed specifically to fit around existing Simpson Strong-Tie® panelized roof hangers such as the F or HFN series. In some cases, existing panelized roof hangers may need replacement due to excessive gapping, damage incurred during field erection or corrosion from roof leaks or condensation. The NRUZ allows you to quickly and effectively match the capacity of these hangers without having to remove the original connectors or disassemble the roof.

Ask a Question
Specifications

Simpson Strong-Tie NRU46Z

•When installed with no more than a 1/8-in. gap between the original hanger and the purlin, the NRUZ series provides equal or greater capacity than Simpson's F, HF and HFN series hangers
•Nominal joist size: 4x6
•Seat width: 3-3/4 inches
•Height: 5-1/4 inches
•Made from 16-gauge steel
•ZMAX galvanization offers extra corrosion resistance for exterior and treated-wood applications




Description

Simpson Strong-Tie NRU46Z

The NRUZ series of retrofit hangers is designed for use on nailers on steel trusses. It is designed specifically to fit around existing Simpson Strong-Tie® panelized roof hangers such as the F or HFN series. In some cases, existing panelized roof hangers may need replacement due to excessive gapping, damage incurred during field erection or corrosion from roof leaks or condensation. The NRUZ allows you to quickly and effectively match the capacity of these hangers without having to remove the original connectors or disassemble the roof.

Additional Information
Type

Hanger
